Standard Permanent Magnetic Lifter
Why Choose Us?
Safety, Magnetism Continue 30years Without Electric. Energy saving,
Above 95%.
The Clamping Force Can Be As nigh As More Than 20 Kg/cm2.
High Efficiency, Improve The efficiency of More Than 60%.
Very Easy to Use, Fast, Durable, Maintenance Free.
Specification sheet
| Model | Rated lifting capacity (Kgf) | Cylindrical lifting force (Kgf) | Dimension (mm) | Max pull-off force (Kgf) | Net Weight(kg) |
| A(length) | B(width) | C(height) | D(Handle length) |
| PML-100 | 100 | 30 | 92 | 65 | 69 | 155 | 350 | 2.5 |
| PML-200 | 300 | 100 | 130 | 88 | 69 | 155 | 900 | 5.5 |
| PML-400 | 400 | 120 | 165 | 95 | 95 | 200 | 1200 | 10 |
| PML-600 | 600 | 200 | 210 | 115 | 116 | 230 | 1800 | 19 |
| PML-1000 | 1000 | 300 | 260 | 135 | 140 | 255 | 3000 | 35 |
| PML-1500 | 1500 | 500 | 340 | 135 | 140 | 255 | 4500 | 45 |
| PML-2000 | 2000 | 600 | 356 | 160 | 166 | 320 | 6000 | 65 |
| PML-3000 | 3000 | 1000 | 444 | 160 | 166 | 380 | 9000 | 85 |
| PML-4000 | 4000 | 1300 | 520 | 175 | 175 | 550 | 12000 | 150 |
| PML-5000 | 5000 | 1500 | 620 | 220 | 220 | 600 | 15000 | 210 |
| PML-6000 | 6000 | 2000 | 650 | 270 | 265 | 700 | 18000 | 300 |
| PML-10000 | 10000 | 3000 | 800 | 235 | 290 | 800 | 30000 | 395 |
| Note: Other specifications can be customized ,please call for further information. |
|
